概要
- 参考にしてた記事で動かんくなってたので辛い
- 改めて整理して色々試して動くようになったのでそれだけ貼り付ける
$ tree
.
├── Dockerfile
├── docker-compose.yml
├── initdb.d
│ └── 01-init.sql
├── mysql
│ └── custom
│ └── my.cnf
├── output
└── schemaspy
└── schemaspy.properties
ファイルの内容
Dockerfile
FROM openjdk:8u212-jdk-alpine
ENV DRIVER_URL https://repo1.maven.org/maven2/mysql/mysql-connector-java/8.0.30/mysql-connector-java-8.0.30.jar
ENV APP_URL https://github.com/schemaspy/schemaspy/releases/download/v6.1.0/schemaspy-6.1.0.jar
WORKDIR /app
COPY schemaspy/schemaspy.properties .
RUN apk --update add graphviz ttf-dejavu && \
apk --update add --virtual .builddep tzdata wget libressl && \
cp /usr/share/zoneinfo/Asia/Tokyo /etc/localtime && \
mkdir /drivers && \
wget -O /drivers/mysql-connector-java.jar ${DRIVER_URL} && \
wget -O schemaspy.jar ${APP_URL} && \
apk del .builddep && \
rm -rf /var/cache/apk/*
docker-compose.yml
version: "3.9"
volumes:
db-store:
services:
db:
image: mysql:8.0-oracle
volumes:
- db-store:/var/lib/mysql
- ./initdb.d:/docker-entrypoint-initdb.d
- ./mysql/custom:/etc/mysql/conf.d
environment:
- MYSQL_DATABASE=my_database
- MYSQL_ROOT_PASSWORD=root
schemaspy:
build:
context: .
image: schemaspy
volumes:
- ./output:/output
tty: true
initdb.d/01-init.sql
CREATE DATABASE IF NOT EXISTS my_database;
USE my_database;
CREATE TABLE `pokemon` (
`id` INT NOT NULL PRIMARY KEY AUTO_INCREMENT,
`name` VARCHAR(255) NOT NULL
);
CREATE TABLE `type` (
`id` INT NOT NULL PRIMARY KEY AUTO_INCREMENT,
`name` VARCHAR(255) NOT NULL
);
CREATE TABLE `waza` (
`id` INT NOT NULL PRIMARY KEY AUTO_INCREMENT,
`name` VARCHAR(255) NOT NULL,
`type_id` INT NOT NULL,
FOREIGN KEY (`type_id`) REFERENCES `type`(`id`)
);
CREATE TABLE `pokemon_type` (
`id` INT NOT NULL PRIMARY KEY AUTO_INCREMENT,
`pokemon_id` INT NOT NULL,
`type_id` INT NOT NULL,
FOREIGN KEY (`pokemon_id`) REFERENCES `pokemon`(`id`),
FOREIGN KEY (`type_id`) REFERENCES `type`(`id`)
);
CREATE TABLE `pokemon_waza` (
`id` INT NOT NULL PRIMARY KEY AUTO_INCREMENT,
`pokemon_id` INT NOT NULL,
`waza_id` INT NOT NULL,
FOREIGN KEY (`pokemon_id`) REFERENCES `pokemon`(`id`),
FOREIGN KEY (`waza_id`) REFERENCES `waza`(`id`)
);
schemaspy/schemaspy.properties
schemaspy.t=mysql
schemaspy.dp=/drivers/mysql-connector-java.jar
schemaspy.host=db
schemaspy.port=3306
schemaspy.db=my_database
schemaspy.s=my_database
schemaspy.u=root
schemaspy.p=root
schemaspy.implied=true
schemaspy.norows=true
schemaspy.nopages=true
mysql/custom/my.cnf
[mysqld]
character-set-server=utf8
[mysql]
default-character-set=utf8
実行
$ docker compose up -d
$ docker compose exec schemaspy java -jar schemaspy.jar -o /output/
